Tektronix MDO4000B Series User Manual

Command Groups
Table 2-36: Power Commands (cont.)
Command Description
POWer:QUALity:DISplay:
ICRESTfactor
This command specifies the display state for the current crest factor readout
POWer:QUALity:DISplay:IRMS This command specifies the display state for the rms current (IRMS) readout
POWer:QUALity:DISplay:
PHASEangle
This command specifies the display state for the phase angle readout
POWer:QUALity:DISplay:
POWERFACtor
This command specifies the display state for the power factor readout
POWer:QUALity:DISplay:REACTpwr This command specifies the display state for the reactive power readout
POWer:QUALity:DISplay:TRUEpwr This command specifies the display state for the true power readout
POWer:QUALity:DISplay:
VCRESTfactor
This command specifies the display state for the voltage crest factor readout
POWer:QUALity:DISplay:VRMS This command specifi es the display state for the rms voltage (VRMS) readout
POWer:QUALity:FREQREFerence This command specifies the power quality frequency reference
POWer:QUALity:FREQuency? Returns the frequency measurement
POWer:QUALity:ICRESTfactor? Returns the current crest factor measurement
POWer:QUALity:IRMS?
Returns the rms current measurement
POWer:QUALity:PHASEangle?
Returns the phase angle measurement
POWer:QUALity:POWERFACtor? Returns the power factor measurement
POWer:QUALity:REACTpwr?
Returns the reactive power measurement
POWer:QUALity:TRUEpwr?
Returns the true power measurement
POWer:QUALity:VRMS?
Returns the rms voltage measurement
POWer:REFLevel:ABSolute Sets the reference levels to their default unit values
POWer:REFLevel:ABSolute:HIGH This command specifies the top reference level for rise time
POWer:REFLevel:ABSolute:LOW This command specifies the low reference level for rise time
POWer:REFLevel:ABSolute:MID<x> This command specifies the mid reference level for measurements
POWer:REFLevel:HYSTeresis This command specifies the measurement reference level hysteresis value
POWer:REFLevel:METHod This command specifies the method used to calculate the 0% and 100% reference level
POWer:REFLevel:PERCent Sets the reference levels to the default percentage values
POWer:REFLevel:PERCent:HIGH This command specifies the top reference percent level for rise time
POWer:REFLevel:PERCent:LOW This command specifies the low reference percent level for rise time
POWer:REFLevel:PERCent:MID<x> This command specifies the mid reference percent level for waveform measurements
POWer:RIPPle Sets the vertical offset of the source waveform
POWer:RIPPle:RESults:AMPLitude?
Returns the peak-to-peak ripple measurement
POWer:RIPPle:RESults:MAX? Returns the maximum of the peak-to-peak ripple measurements
POWer:RIPPle:RESults:MEAN? Returns the mean of the peak-to-peak ripple measurements
POWer:RIPPle:RESults:MIN? Returns the minimum of the peak-to-peak ripple measurement
POWer:RIPPle:RESults:STDdev? Returns the standard deviation of the peak-to-peak ripple measurements
POWer:RIPPle:SOUrce This command specifies the source waveform for ripple tests
2-44 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
