Tektronix MDO4000B Series User Manual

Command Groups
Table 2-36: Power Commands (cont.)
Command Description
POWer:SOA:LINear:XMAX This command specifies the user XMAX value for use in linear SOA calculations
POWer:SOA:LINear:XMIN This command specifies the user XMIN value for use in linear SOA calculations
POWer:SOA:LINear:YMAX This command specifies the user YMAX value for use in linear SOA calculations
POWer:SOA:LINear:YMIN This command specifies the user YMIN value for use in linear SOA calculations
POWer:SOA:LOG:XMAX This command speci fies the user XMAX value for use in log SOA calculations
POWer:SOA:LOG:XMIN This command specifies the user XMIN value for use in log SOA calculations
POWer:SOA:LOG:YMAX This command speci fies the user YMAX value for use in log SOA calculations
POWer:SOA:LOG:YMIN This command specifies the user YMIN value for use in log SOA calculations
POWer:SOA:MASK:DEFine This command specifies the X (volts) and Y (Amps) coordinates of the current SOA mask
POWer:SOA:MASK:MAXAmps This command specifies the maximum current applied to SOA mask testing
POWer:SOA:MASK:MAXVolts This command specifies the maximum voltage applied to SOA mask testing
POWer:SOA:MASK:MAXWatts This command specifi es the maximum power applied to SOA mask testing
POWer:SOA:MASK:NR_Pt? Returns the number of mask points defined
POWer:SOA:MASK:STAT E This command specifies the state of the m ask for SOA calculations
POWer:SOA:MASK:STOPOnviol This command specifies the enabled state of the mask stop on violation condition
POWer:SOA:PLOTTYPe This command specifies the SOA plot type
POWer:SOA:RESult:FAILures:QTY? Returns the number of failures in the test
POWer:SOA:RESult:NUMACq? Returns the number of acquisitions in the test
POWer:SOA:RESult:STATE? Returns the pass/fail state of the SOA test
POWer:STATIstics Clears all the accumulated statistics of all measurements
POWer:STAT Istic s:M ODe Enables or disables the display of the m easurement statistics
POWer:STATIstics:WEIghting Sets the number of samples which are included for the statistics computations for m ean
and the standard deviation
POWer:SWLoss:
CONDCALCmethod
This command specifies the power application switching loss conduction calculation method
POWer:SWLoss:CONDuction:
ENERGY:MAX?
Returns the maximum conduction energy for the switching loss calculation
POWer:SWLoss:CONDuction:
ENERGY:MEAN?
Returns the mean conduction energy for the switching loss calculation
POWer:SWLoss:CONDuction:
ENERGY:MIN?
Returns the minimum conduction energy for the switching loss calculation
POWer:SWLoss:CONDuction:
POWer:MAX?
Returns the maximum conduction power for the switching loss calculation
POWer:SWLoss:CONDuction:
POWer:MEAN?
Returns the mean conduction power for the switching loss calculation
POWer:SWLoss:CONDuction:
POWer:MIN?
Returns the minimum conduction power for the switching loss calculation
POWer:SWLoss:DISplay This command specifies the display selection for switching loss results
POWer:SWLoss:GATe:PO Larity This command specifies the switching loss gate polarity
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-45
