Ampliﬁer Replaceable Parts

Table 39: Power

cord identiﬁ cation

Plug conﬁguration Normal usage Option number/

North America

120 V

Standard 161-0066-00

Universal Eu

A1 161-0066-

United Kingdom A2 161-0066-10

Australi

A3 161-00

66-11

Switzer

land

A5 161-0154-00

Japan A6 161-A005-00

China AC 161-0306-00

No po

wer cord supplied.

A99

86 TCPA300/400 Ampliﬁers and TCP300/400 Series Current Probes Service Manual
