Tektronix TCP300 Series Service Manual

Current Probes Replaceable Parts
Table 42: TCP30
5 and TCP312 replaceable parts list
Fig. &
Index
Number
Tektronix
Part
Number
Serial No.
Effective
Serial No.
Discont’d Qty Name & Description
41-1 204-0288-XX 1
BODY HALF,PROBE:UPPER BODY HALF,BLACK,POLY
-2 214-0835-XX 1
SPRING,HLCPS:0.127 OD X 2.65 L,SST
-3 214-0849-XX 1
RTNR RETURN SPR:BRS CD PL
-4 352-0106-XX 1
HOLDER,SPR RTNR:DELRIN
-5
174-4690-XX 1
CABLE ASSY,RF COAX,60.0 L
-6 671-5427-XX 1
CKT BD ASSY, TCP305
671-5433-XX 1
CKT BD ASSY, TCP312
-7
213-0087-XX 2
SCREW,TPG,TC:2-32 X 0.5,TYPE BT,PANHEAD,STEEL,CADIUM
PLATED,POZIDRIVE
-8 335-0906-XX 1
MARKER,IDENT:PROBE IDENT LABEL,TCP305
335-0907-XX 1
MARKER,IDENT:PROBE IDENT LABEL,TCP312
-9 204-0714-XX 1
BODY,HALF:LOWER BODY HALF W/CONTACTS
-10 120-1984-XX 1
XFMR SUBASSY:UPPER & LOWER TRANSFORMER SUBASSY, TCP305
120-2029-XX 1
XFMR SUBASSY:UPPER & LOWER TRANSFORMER SUBASSY, TCP312
-11 214-0854-XX 1
CONTACT,ELEC:UPPER SHELF,CU BE
-12 351-0121-XX 1
CONT ASSY,ELEC:PROBE SLIDE ASSY
-13 214-0997-XX 1
BALL,BEARING:0.094,SST
Standard Accessories
-14 196-3120-XX 1
LEAD,ELECTRICAL:23 AWG,6.0 L,GROUND
-15 016-1923-XX 1
COVER,PROBE,SMALL
071-1185-XX 1
INSTRUCTION SHEET,TCP300/400 SERIES CURRENT PROBES
