Tektronix TCP300 Series Service Manual

TCP305 and TCP312 Performance Verification
TCP312 Curren
t Probe Test Record
Photocopy this form and use it to record the performance test results.
TCP312 test record
Instrument S erial Number: Certificate Number:
Temperature
:
Relative Humidity %:
Date of Calibration:
Technician
:
Performance test
Range,
A/V Test Minim um Measured/calculated Maximum
0.20 A
-3% +3%
0.60 A
-3% +3%
DC Gain A ccuracy
(% Error)
1A/V
1.00 A
-3% +3%
1.20 A
-3% +3%
3.60 A
-3% +3%
10 A/V
6.00 A
-3% +3%
Rise Ti
me
1A/V
—
≤3.5 ns
Bandw
idth
1A/V
.707
——
30 TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Service Manual
