Tektronix TCP300 Series Service Manual

TCP305 and TCP312 Performance Verification
TCP305 Curren
t Probe Test Record
Photocopy this form and use it to record the performance test results.
TCP305 test record
Instrument Serial Number: Certificate Number:
Temperature
:
Relative Humidity %:
Date of Calibration:
Technician
:
Performance test
Range,
A/V Test Minimum Measured/calculated Maximum
1.00 A
-3% +3%
3.00 A
-3% +3%
DC Gain Accuracy
(% Error)
5A/V
5.00 A
-3% +3%
2.00 A
-3% +3%
6.00 A
-3% +3%
10 A /V
10.00 A
-3% +3%
Rise T
ime
5A/V
—
≤7ns
Bandw
idth
5A/V
0.707
——
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Service Manual 29
