Tektronix TCP300 Series Service Manual

TCP305 and TCP312 Performance Verification
Required Test Equipment
To perform the acceptance tests in this section, you will need the test equipment
listed. The test equipment must meet or exceed the specifi cations listed. The test
procedures may need to be modified if the recommended equipment is not used.
Table 11: Required test equipment
Qty Item Description Recommended
1
Oscilloscope
500 MHz bandwidth
Tektronix TDS5000
1
Current Probe Amplifier Tektronix TCPA300
1
Leveled Sine Wave Generator
3 MHz to 100 MHz
Wavetek 9100 with Option 250
1
High Amplitude Pulse Generator
Rise time <1 ns, pulse width > 100 ns
amplitude >5 V
p-p
into 50 Ω
Picosecond Labs 2600
1 Digital Multimeter
DCV: 0.1% accuracy 5
1
/
2
digit
resolution
Keithley 2700
1
Current Source DCA: 0.1% accuracy, 0 to ±10 A
Wavetek 9100
1
HF Current Loop 50 Ω , BNC Connector
Tektronix part number 015-0601-50
1
DC Current Loop 5 turns 18 AWG coated wire (See page 4, Making DC Current
Loops.)
1 Precision Termination
50 Ω ±0.1% , 0.5 W
Tektronix part number 011-0129-00
1
BNC Cable 50 Ω, 0.76 m (30 in) long
Tektronix part number 012-0117-00
1
Cable TEKPROBE Interface Cable
Tektronix part number 012-1605-00
1 Adapter
BNC-to-Dual Banana
Tektronix part number 103-0090-00
