Tektronix TCP300 Series - TCP404 XL Current Probe Test Record

TCP303 and TCP404XL Performance Verification
TCP404XL Curr
ent Probe Test Record
Photocopy this form and use it to record the performance test results.
TCP404XL test record
Instrument Serial Number: Certificate Number:
Temperature
:
Relative Humidity %:
Date of Calibration:
Technician
:
Performance test Range Test Minimum Measured/calculated Maximum
3.0 A
-3% +3%
9.0 A
-3% +3%
DC Gain Accuracy (% Error) 1 A/mV
15.0 A
-3% +3%
Rise Tim
e
1A/mV
——
175 ns
Bandwi
dth
1A/mV
—
2MHz
——
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Service Manual 43
