Status and Events

TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer

3-21

Table 3- 5: Execution error messages – EXE bit 4 (Cont.)

Code Message

2225 Measurement error, No waveform to measure

2226 Null Waveform

2227 Positive and Negative Clipping

2228 Measurement error, Positive Clipping

2229 Measurement error, Negative Clipping

2230 Measurement error, High Ref < Low Ref

2235 Math error, Invalid math description

2241 Waveform request is invalid

2242 Data start > record length

2243 Waveform requested is not a data source

2244 Waveform requested is not turned on

2245 Saveref error, Selected channel is turned off

2246 Saveref error, Selected channel data invalid

2248 Saveref error, Source reference data invalid

2260 Calibration error

2301 Cursor error, Off screen

2302 Cursor error, Cursors are off

2303 Cursor error, Cursor source waveform is off
