Status and Events
3-22
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
Table 3--6 lists the device errors that can occur during oscilloscope
operation. These errors may indicate that the oscilloscope needs
repair.
Table 3- 6: Device error messages – DDE bit 3
Code Message
300 Device-specific error
310 System error
311 Memory error
313 Calibration memory lost
314 Save/recall memory lost
315 C onfiguration memory lost
350 Q ueue overflow (does not set DDE bit)
361 Parity error in program message (check parity)
362 Framing error in program message (check baud rate)
363 Input buffer overrun (check flagging)
Table 3--7 lists the system event messages. These messages are
generated whenever certain system conditions occur.
Table 3- 7: System event messages
Code Message
400 Q uery event
401 Pow er on (PON bit 7 set)
402 O peration complete (OPC bit 0 set)
403 U ser request (URQ bit 6 set)
404 Power fail (DDE bit 3 set)
405 R equest control
