Command Groups
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
2-31
Table 2- 20: Power Measurement commands (TPS2000 with TPS2PWR1
only) (Cont.)
Header Description
SWLoss:TOFFEND Set or query a level on the first falling edge of the
current waveform that occurs after the turn-off starts
SWLoss:TONEND Set or query a level on the first rising edge of the
voltage waveform that occurs after the first falling
edge
SWLoss:TOFFSTART Set or query a level on the falling edge of the voltage
waveform that defines where the beginning of the
switching loss measurement ends
SWLoss:TONSTART Set or query a level on the falling edge of the voltage
waveform that defines where the switching loss
measurement begins
SWLoss:UNIts Set or query the units for Switching Loss Measure-
ment
SWLoss:VALue:CONDUCTION? Return the power loss of the device under test when
the device is conducting in its on state
SWLoss:VALue:TOTAL? Return the sum of the turn-on, turn-off, and
conduction switching losses
SWLoss:VALue:TURNOFF? Return the power loss of the device under test when
the device is transitioning between its on and off
state
SWLoss:VALue:TURNON? Return the power loss of the device under test when
the device is transitioning between its off and on
state display
SWLoss:VSAT Set or query the saturation voltage for the device
under test
WAVEFORMANALYSIS:SOUrce Set or query the source for Waveform Analysis
commands
