Tektronix WFM6120 Service Manual

Replaceable Parts
Table 5-1: Circuit boards and connectors (See Figure 5-1.) (cont.)
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont’d Qty Name & descri
ption
671-6302-00 1
CIRCUIT BD ASSY; DUAL CHANNEL MAIN, 389395500 WIRED
(WFM7020, W
FM7120)
-9
671-6379-00 1
CIRCUIT BD ASSY; DUAL CHANNEL MAIN, 389395500 WIRED
(WFM6120 O
NLY)
-10 119-6801-00 1
POWER SUPPLY; 110W,AC-DC,5VDC 22A OUT,90-264VAC 47-63HZ
IN,PFC,75
%EFF
-11 337-4342-00 1
SHIELD, POWER SUPPLY; .050 AL, 5052-H32, MILL FINISH;
-12 174-4769
-00
1
CA ASSY,SP; HV,BR,15.00 L & 4.00 L;CONN EACH END;LINE FILTER
TO PWR SUPPLY
-13 441-2359
-00
1
CHASSIS,MAIN; 0.050 AL,SAFETY CONTROLLED
-14 134-0246-00
*
PLUG,HO
LE COVER; BUTTON PLUG,;0.578 HEAD DIA X 0.406
THK,ACCOM 0.5 DIA HOLE,0.015-0.125 THK PNL,NYLON,BLACK,94V-2;
-15 210-0457-00 1
NUT,PL,
ASSEM WA; 6-32 X 0.312,STL CD PL,W/LOCKWASHER
-16 211-0410-00 2
SCR,ASSEM WSHR; 4-40 X 0.437,PNH,STL,CDPL,T-10 TORX DR
-17 131-41
31-00
1
CONN,PLUG,ELEC; MALE W/LOCKING ADPTR,EXT MTG,SAFETY
CONTROLLED
-18 211-0
734-00
4
SCREW,MACHINE; 6-32 X 0.250,FLH100,STL,CDPL,T-10 TORX DR
-19 119-7086-00 1
FILTE
R,EMI; AC LINE CONNECTOR/INPUT
FILTER;6.0A,120-250VAC,DC-400 HZ,2.2 NF CY,100 NF CX,IEC
INPUT,FAST-ON/SOLDER LUG OUTPUT,CHASSIS MOUNT,SAFETY
CONT
ROLLED;FN9222-6/06
-20 211-0722-00 2
SCREW,MACHINE; 6-32 X 0.250,PNH,STL,CDPL,T-15 TORX DR
-21 174-
5030-00
1
CABLE ASSEMBLY; POWER: PWR SUPPLY TO MAIN BD
-22 129-1617-00 2
*
1/4
HEX MALE -FEMALE STANDOFF (ONLY WHEN MEZZANINE BOARD
IS INSTALLED)
-23 220-0497-00
*
NUT
,PLAIN,HEX; 0.5-28 X 0.562 HEX,BRS CD PL
-24 210-1039-00 21
*
WASHER,LOCK; 0.521 ID,INT,0.025 THK,SST
-2
5
13
1-M057-00
3
CONN,RF:PCB,FEMALE,BNC,75OHM,EDGE LAUNCH TYPE
671-6281-00 1
CI
RCUIT BD SUBASSY; I/O MEZZANINE BD; 389358000;TESTED
(WFM7120, WFM7020)
-26
671-5809-00 1
C
IRCUIT BD SUBASSY; I/O MEZZANINE BD; 389358000;TESTED
(WFM6120 ONLY)
-27 174-4586-00 1
C
A ASSY; RIBBON,2.0 L,DOUBLE ENDED,IDC,FEMALE,2 X 20,0.050
CTR,PLZ (W/MEZZANINE BOARD ONLY)
-28 211-0711-00 2
*
SCREW,MACHINE; 6-32 X 0.250,PNH,STL,CDPL,T-15 TORX DR
(W/MEZZANINE BOARD ONLY)
-29 214-3903-00 6
SCREW,JACK; 4-40 X 0.312 LONG,0.188 H HEX HEAD STAND OFF,4-40
INT THD, X 0.312 THD EXT 4-40
-30 131-7582-00 1
CONN,DSUB; PCB;FEMALE,RTANG,DUAL STACKED,15 POS HD
LOWER,9 POS UPPER,SAFETY CONTROLLED
-31 211-0722-00 9
SCREW,MACHINE; 6-32 X 0.250,PNH,STL,CDPL,T-15 TORX DR
-32 131-7257-00 1
CONN,JACK; PCB/PNL,RJ45,CAT5,W/LEDS YELLOW &
GREEN,FEMALE,RTANG,8 POS,0.1 CTR,0.528 H X 0.138 TAIL,10/100
BASE TX AND RX MAGNETICS MODULE,SAFETY CONTROLLED
WFM6120, WFM7020, and WFM7120 Waveform Monitors Service Manual 5–3
