Field Description
er as so-called hyper channels. You can also group together
channels as PPP multilink channel bundles.
Timeslots divide the available 2 Mbps bandwidth of an S2M
connection into logical channels. No distinction is made below
between timeslots and channels, as the difference is immaterial
for configuration purposes.
A list of the channel bundles already configured is shown.
Click Add to configure new channel bundles.
You can use the Add at Custom Time Slots to configure additional bundles.
Note
This function is only available for leased lines.
Fields in the New Bundle menu.
Field Description
Description Enter the name of the channel bundle.
Bundle Type
Displays the type of channel bundle.
Possible values:
•  %3,,7: The channels are bundled as PPP Multilink
channels.
• &#", ?&)",: The channels are bundled as
physical hyperchannels.
Timeslot Selection Select between @  *," and (#, %<.
Timeslot Range
Only if Timeslot Selection = @  *,"
Shows the logical channels (timeslots) combined to form this
channel bundle.
• 9: Shows the first of the channels used for this channel
bundle. Possible values:  to $.
• : Shows the last of the channels used for this channel
bundle. Possible values:  to $.
Teldat GmbH
11 Physical Interfaces
bintec Rxxx2/RTxxx2 133
