Note
In the ex works state the DHCP pool is preconfigured with the IP addresses
192.168.0.10 to 192.168.0.49 and is used if there is no other DHCP server available in
the network.
21.4.2.1 Edit or New
Choose the New button to set up new IP address pools. Choose the icon to edit exist-
ing entries.
Fig. 175: Local Services->DHCP Server+DHCP Configuration->New
The Local Services->DHCP Server+DHCP Configuration->New menu consists of the
following fields:
Fields in the menu Basic Parameters
Field Description
Interface Select the interface over which the addresses defined in IP Ad-
dress Range are to be assigned to DHCP clients.
When a DHCP request is received over this Interface, one of
the addresses from the address pool is assigned.
IP Pool Name Enter any description to uniquely identify the IP pool.
Teldat GmbH
21 Local Services
bintec Rxxx2/RTxxx2 447
