5.5.2 Sensor Type
To enter non-
intrusive operation during the Normal
Operating Mode, place the magnetic wand over the CH1
designation. The
will display the sensor type for
channel 1 for 5 seconds then enter in the Zero Menu.
NOTE:
If you want to operate channel 2, place the magnetic
wand on CH2 first to enter the setup menu.
Once non-intrusive mode is entered, placing the magnetic
wand over CH1, will allow scrolling through all of the
functions that are available. Once the desired
function is
reached, a 10-second timer will appear on the bottom row
of the LED display. During this 10-
second time out, if the
magnetic wand is placed over CH2, that function is entered.
Once a function is entered, a new timer will appear.
Figure 5-6 Sample Display
Entering Non-Intrusive Mode
5.5.3 Zeroing
Zeroing is the first option in the setup menu. A “0 ” is
displayed in the status bit of the display to designate this
function. A 10 second timer is displayed on the bottom line of
the LED display. To initiate zeroing, place the magnetic wand
over CH2 during the 10-second countdown. If you do not
initiate zeroing during the 10-second countdown, the
will return to the Normal Operating Mode. To abort zeroing
at any time, place the magnatic wand over CH1.
If you initiate zeroing, the status bit will start to flash. Once
zeroing is complete, the unit will return to the Normal
Operating Mode.
Figure 5-7 Sample Zeroing
Display
