iTRANS 2
FIXED POINT SINGLE OR DUAL GAS MONITOR
WITH DUAL ANALOG OUTPUTS
USER MANUAL
Revision 7.0
Command 130 – Read Real Time Clock – Response Length: 18 Bytes
Byte Number Parsing Parameter
0 Unsigned-8 RTC Minute Channel 1
1 Unsigned-8 RTC Hour Channel 1
2 Unsigned-8 RTC Day Channel 1
3 Unsigned-8 RTC Month Channel 1
4 Unsigned-8 RTC Year Channel 1
5-8 Unsigned-32 Total Operation Time (In Minutes) Channel 1
9 Unsigned-8 RTC Minute Channel 2
10 Unsigned-8 RTC Hour Channel 2
11 Unsigned-8 RTC Day Channel 2
12 Unsigned-8 RTC Month Channel 2
13 Unsigned-8 RTC Year Channel 2
14-17 Unsigned-32 Total Operation Time (In Minutes) Channel 2
Command 131 – Read User Configuration – Response Length: 36 Bytes
Byte Number Parsing Parameter
0-3 Float IEEE 754 Low Alarm Threshold Channel 1
4-7 Float IEEE 754 High Alarm Threshold Channel 1
8-11 Float IEEE 754 Analog Output Range Channel 1
12-15 Float IEEE 754 Cal Gas Value Channel 1
16-17 Unsigned-16 Calibration Interval In Days Channel 1
18-21 Float IEEE 754 Low Alarm Threshold Channel 2
22-25 Float IEEE 754 High Alarm Threshold Channel 2
26-29 Float IEEE 754 Analog Output Range Channel 2
30-33 Float IEEE 754 Cal Gas Value Channel 2
34-35 Unsigned-16 Calibration Interval In Days Channel 2
Command 132 – Read Live Channels Information – Response Length: 26 Bytes
Byte Number Parsing Parameter
0-3 Float IEEE 754 User Peak Channel 1
4-5 Unsigned-16 Previous OR Channel 1
6 Unsigned-8 Last Alarm Day Channel 1
7 Unsigned-8 Last Alarm Month Channel 1
8 Unsigned-8 Last Alarm Year Channel 1
9-10 Unsigned-16 Max Temperature Channel 1
11-12 Unsigned-16 Min Temperature Channel 1
13-16 Float IEEE 754 User Peak Channel 2
17-18 Unsigned-16 Previous OR Channel 2
19 Unsigned-8 Last Alarm Day Channel 2
20 Unsigned-8 Last Alarm Month Channel 2
21 Unsigned-8 Last Alarm Year Channel 2
22-23 Unsigned-16 Max Temperature Channel 2
24-25 Unsigned-16 Min Temperature Channel 2
