Command 133 – Read Live Channels Identifier – Response Length: 66 Bytes
Byte Number Parsing Parameter
0 Unsigned-8 Sensor Type Code Channel 1
1 Unsigned-8 Gas Type Code Channel 1
2 Unsigned-8 Decimal Place Channel 1
3-4 Latin-1 ASCII Sensor ID Byte Channel 1
5-6 Latin-1 ASCII Sensor ID Number Channel 1
7-16 Latin-1 ASCII Sensor Part Number Channel 1
17-32 Latin-1 ASCII Sensor Serial Number Channel 1
33 Unsigned-8 Sensor Type Code Channel 2
34 Unsigned-8 Gas Type Code Channel 2
35 Unsigned-8 Decimal Place Channel 2
36-37 Latin-1 ASCII Sensor ID Byte Channel 2
38-39 Latin-1 ASCII Sensor ID Number Channel 2
40-49 Latin-1 ASCII Sensor Part Number Channel 2
50-65 Latin-1 ASCII Sensor Serial Number Channel 2
Command 134 – Read Instrument Identifier – Response Length: 50 Bytes
Byte Number Parsing Parameter
0-1 Latin-1 ASCII Instrument Config Map Version
2-17 Latin-1 ASCII Instrument Part Number
18-33 Latin-1 ASCII Instrument Serial Number
34-37 Latin-1 ASCII Technician Initials
38-43 Latin-1 ASCII Instrument Job Number
44-49 Latin-1 ASCII Manufacture Date
Command 135 – Read Calibration Data – Response Length: 18 Bytes
Byte Number Parsing Parameter
0-3 Float IEEE 754 Span Reserve Value Channel 1
4 Unsigned-8 Last Cal Day Channel 1
5 Unsigned-8 Last Cal Month Channel 1
6 Unsigned-8 Last Cal Year Channel 1
7-8 Unsigned-16 Next Cal Due In Days Channel 1
9-12 Float IEEE 754 Span Reserve Value Channel 2
13 Unsigned-8 Last Cal Day Channel 2
14 Unsigned-8 Last Cal Month Channel 2
15 Unsigned-8 Last Cal Year Channel 2
16-17 Unsigned-16 Next Cal Due In Days Channel 2
Table A - 3 Read Commands
