6.2.4.7 LNB Type
None This indicates that no LNB is fitted.
Other This indicates that an LNB is fitted but is not one of the
Paradise LNBs listed below.
C 3.635 – 4.200 GHz This presets the LNB LO frequency to 5150MHz.
Ku 10.95 – 11.45 GHz This presets the LNB LO frequency to 10000MHz
Ku 11.2 – 11.7 GHz This presets the LNB LO frequency to 10250MHz
Ku 11.7 – 12.2 GHz This presets the LNB LO frequency to 10750MHz
Ku 12.25 – 12.75 GHz This presets the LNB LO frequency to 11300MHz
Table 6-31 LNB Type
6.2.4.8 LNB LO Frequency
Range: -99.999GHz to 99.999GHz; step size: 0.0000001GHz
Description: This is the local oscillator frequency of the LNB.
Table 6-32 LNB LO Frequency
6.2.4.9 DC to LNB
This is an On/Off control used to enable and disable the DC power supply from the
modem to the LNB.
6.2.4.10 10MHz to LNB
This is an On/Off control used to enable and disable the 10MHz reference from the
modem to the LNB.
6.2.4.11 Mute LNB Services in Standby
This is an On/Off control used to enable and disable the transfer of LNB DC and 10MHz
services from a failed modem to a backup modem in a 1:1 or 1:N redundancy system.
Setting the checkbox causes the services to switch over from the online modem to the
backup modem on a failure.
6.2.5 Edit->Unit Screen
The Edit->Unit screen contains the following tab menu options:
