Q-Flex Satellite Modem Installation and Operating Handbook
6-48
Modem Settings
Ethernet Operation
Bridging
/Routing
Mode
M&C and IP
Traffic
Ethernet
Ports
TCP
Acceleration
Operation of
M&C
Ethernet
Port
Operation of
IP Traffic
Ethernet
Port
Bridging Bridged Off M&C address
shared with IP
Traffic port; M&C
traffic will be
bridged over
satellite as required
IP Traffic address
not used; port is
addressed via
M&C address;
traffic will be
bridged over
satellite as
requried
Bridging Bridged On This combination of modem settings is
illegal (M&C port will be automatically
removed from bridge)
Bridging Not bridged Off M&C port has
dedicated address;
M&C traffic will not
be bridged over
satellite
IP Traffic port has
dedicated address;
traffic will be
bridged over
satellite as
required
Bridging Not bridged On M&C port has
dedicated address;
M&C traffic will not
be bridged over
satellite; modem
gateway is applied
to M&C subnet
IP Traffic address
not used; IP Traffic
port dedicated to
satellite traffic only,
which will be
accelerated and
bridged over
satellite as
required
Routing Bridged Off This combination of modem settings is
illegal (M&C port will be automatically
removed from bridge)
Routing Bridged On This combination of modem settings is
illegal (M&C port will be automatically
removed from bridge)
Routing Not bridged Off M&C port has
dedicated address,
which must be on a
different subnet to
IP Traffic port; M&C
traffic will be routed
over satellite as
required
IP Traffic port has
dedicated address;
traffic will be
routed over
satellite as
required
Modem gateway applied to either port as
specified by subnet
Routing Not bridged On M&C port has
dedicated address,
which must be on a
different subnet to
IP Traffic port; M&C
traffic will be routed
and accelerated
over satellite as
required
IP Traffic port has
dedicated address;
traffic will be
routed and
accelerated over
satellite as
required
Modem gateway applied to either port as
specified by subnet
Table 6-51 Ethernet Port Operation
