Q-Flex Satellite Modem Installation and Operating Handbook
6-33
Table 6-33 defines the serial M&C RS485 interface pinout when IP-Remote is selected
(refer to Chapter 11 for full connector pinouts).
Pin Signal
Name
Direction RS485: IP – Remote Mode
Shield/Gnd
Shield/Gnd
3 Master-B + to modem TX-B
4 Slave-B + from modem RX-B
5 Shield/Gnd
6 Slave-A - from modem RX-A
9 Master-A - to modem TX-A
Table 6-38 Serial M&C Interface RS485 Pinout (IP Remote Mode)
Range: 1 to 255; step size: 1
Description: This is the RS485 address that is assigned to the modem’s serial M&C
interface.
Table 6-39 Serial M&C Interface RS485 Address
Range: 110, 150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600,
76800, 115200
Description: This sets the baud rate associated with the modem’s serial M&C
interface.
Table 6-40 Serial M&C Interface Baud Rate
6.2.6.7 Modem Identity
The Modem identifier is a user-assigned text string that is typically used to uniquely
identify the modem, satellite service or location. It is displayed as the ID field on the left-
hand-side of every web page.
6.2.7 Edit->Unit->M&C->SNMP Screen
The Edit->Unit->M&C->SNMP screen is shown in Figure 6-11.
