TMP4100-Series Installation/Maintenance
33480D01.DOC 1-1
Section 1
Installation
1.1 OVERVIEW
This section documents the installation of TMP4100, TMP4100E, TMP4150, and TMP4155 marking heads.
The TMP4100, TMP4150, and TMP4155 heads contain a pneumatic pin that uses air pressure to drive the pin
from and return the pin to the pin cartridge. The TMP4100E (electric) head uses no air pressure. The
TMP4100E uses an electric solenoid to drive and an internal spring to assist pin return.
Installation of the marking heads is almost identical. Where variation do exist, they will be clearly identified
within the text to inform you of the differences.
TMP4100, TMP4100E: The TMP4100 and TMP4100E markers are hand-held markers. They may be used in
any orientation except inverted
(that is, with the handle pointing upward).
TMP4150, TMP4155: The TMP4150 and TMP4155 are fixture-mounted markers for in-line use. They may be
mounted in any orientation except inverted
(that is, with the mounting holes pointing upward). Typically,
they should be mounted on a tooling fixture with the pin pointing downward. The TMP4150 and TMP4155
marking heads employ a protective boot to help prevent contaminants from entering the marking head cavity.
