TMP4100-Series Installation/Maintenance
33480D01.DOC 2-21
Change 1
2.9 REFERENCE DATA
The following information will assist you in obtaining components to maintain the marking head.
2.9.1 Replacement Parts
Refer to Table 2-6 for a list of replaceable components and their part numbers. Additional tables in this
section list impact pins and pin cartridge assemblies that may be used with the TMP4100-Series markers.
Table 2-6. TMP4100-Series Replacement Parts
PART NO. DESCRIPTION TMP4100 TMP4100E TMP4150 TMP4155
24176 Cable Assembly, Marker, 8 m (26 ft.) long, Extension
● ● ● ●
24682 Cable Assembly, Marker, 38 ft. (11.5 m) long, Extension
● ● ● ●
30306 Marker Assembly, TMP4100, Pneumatic
●
38297 Marker Assembly, TMP4100E, Electric
●
38451 Marker Assembly, TMP4150
●
44320 Marker Assembly, TMP4155
●
27278 Pneumatic Assembly, Filter/Regulator, Mini, Metric
●
40826 Pneumatic Assembly, Filter/Regulator, Mini
● ●
27339 Solenoid Valve
●
35014 Solenoid Valve
● ● ●
30953 Standoff, Marker
●
30942 Standoff, Marker
●
35084 Tubing Set, 6mm x 12 ft. (3.6 m), Black/Clear
● ●
26506 Tubing, Poly, 6mm, Black, Legris
●
Table 2-7. Cartridge Assemblies
PART NO. DESCRIPTION TMP4100 TMP4100E TMP4150 TMP4155
37148 150S Cartridge Kit (impact pin not included)
● ● ●
37149 25XL Cartridge Kit (impact pin not included)
● ● ●
26862 25XLE Cartridge Kit (impact pin not included)
●
41150 25L Extended-Body Cartridge (impact pin not included)
● ●
Table 2-8. Cartridge Compression Springs
PART NO. DESCRIPTION TMP4100 TMP4100E TMP4150 TMP4155
26822 Compression Spring (Return Spring for 25XLE pin)
●
