Activated microphones are indicated by following icon
Microphones in request ar are indicated by following icon
5.7.1 Disconnected units
If delegate units are disconnected or lost RF link with the WCAP due to removed or depleted battery for
instance, to long distance from WCAP ..they are shown as greyed out in the monitoring screen
A unit that lost connection to the wcap will be shown greyed out after +/_ 30 sec
5.8 Conference options
5.8.1 Max active microphones
Max 6 microphones can be on at the same time .
Chairman units always have priority and if max is reached , microphone of the delegate units
will be deactivated to allow chairman units to switch on their microphone . In this case the
microphone of the delegate unit which was switched on the longest , will be deactivated
automatically .
5.8.2 Microphone modes
