Tera TR-590 - Technical Specifications

TERA TR-590
47
Specication
Frequency Range VHF: 136 ~ 174 MHz (Rx/Tx)
UHF: 400 ~ 470 MHz (Rx/Tx)
Channel Number 199 Channels
Voltage DC 6.6 V ~ 8.4 V
Termperature
Range
-25 C ~ 55 C
Operation Single or Dual Receive
Output Power VHF: 5/3/.5 W; UHF: 5/2/.5 W
Modulation Wide / Narrow Band
Max. Deviation ≤±5 KHz for Wide Band
≤±2.5 KHz for Narrow Band
Residual Wave
Transmit
≤-36 dB
Frequency Stability ±2.5 PPM
Receiving
Sensitivity
0.2 μV ( ≥18 dB )
Max. Audio Power
≥700 mW
Weight
237g
Dimension
124x62x36 mm
Note
Without notice, specification are subject to change, according to technological improvements.
