Teradek CUBE Series User Manual

Menu System Dashboard
Dashboard is the landing page after logging on. Clicking the Play button next
to the stream downloads a VLC shortcut. Clicking the shortcut in your
downloads folder launches the video stream in VLC*.
*Note: VLC must be installed on your machine to launch video from the
shortcut. When launching from TeraCentral, VLC is imbedded in TeraCentral, so
there is no need to download it.
17
The video
thumbnail, video
input mode, and
video output
settings are
displayed here.
Choose your
decoder, then use
the slider bar for
quick video
encoder
configuration
Network settings
are displayed here.
Click the arrow to
download a VLC
shortcut used to
launch video.
Use this area to
customize your
stream settings.

Teradek CUBE Series Specifications

General

Video Inputs	HDMI, SDI
Video Outputs	HDMI, SDI
Supported Resolutions	Up to 1080p60
Video Compression	H.264
Audio Compression	AAC
Streaming Protocols	RTMP, RTSP, HLS
Ethernet	10/100/1000 Mbps
Wi-Fi	802.11 a/b/g/n
