Pairing Your Cube Encoder &
Decoder Using the Reset Button
1. Ensure the Cube Encoders and Decoders are on the same network
2. Ensure that your Encoder is not in Canon 5D (HDMI models)
•
Navigate to System - Hardware IO in the Encoder menu system and
select Button Mode - Standard.
3. Press and hold the Reset button on the Encoder for approximately 5-9
seconds. When the ENC and WiFi LEDs flash green release the button.
4. Next, press and hold the Reset button on the Decoder for approximately
5-9 seconds. When the DEC and WiFi LEDs flash green release the button.
The Cubes will pair automatically.
