Power Connection
Male 0B.304
LEMO on Cable
Female 0B.304
LEMO in Cube
4.
3.
1.
2.
1.
2.
4.
3.
Cube features a 4 pin LEMO connector for power. An AC Power adapter is
provided with Cube. Teradek offers accessory cables for a variety of popular
connections including PowerTap, XLR, RED ONE specific. Accessories are
available at www.teradek.com/cube or from your local Teradek dealer.
LEMO Pin Configuration:
1. DC +
2. GP Input (future)
3. GP Output (future)
4. DC -
