Model TA50RT
Rev. 1 04/99
SAFETY
2
2 - 8
2.2.5. TORQUE CHART
ITEM BOLT SPECIFICATION REQUIRED TORQUE
Thread Size Grade Nm. lbft.
Wheel Nut M18 10.9 200 147.5
Slewring Bolt M14 10.9 190 140
Slew Gearbox Bolt M12 12.9 160 118
Axle Clamping Bolt M20 10.9 200 147.5
General Bolts M8 8.8 27.5 20
General Bolts M10 8.8 55 40.5
General Bolts M12 8.8 95 70
General Bolts M16 8.8 236 174
General Bolts M8 10.9 39 29
General Bolts M10 10.9 70 51.5
General Bolts M12 10.9 134 99
General Bolts M16 10.9 333 245.5
General Bolts M10 12.9 85 62.5
General Bolts M12 12.9 160 118
