Terex TA50RT - Machine Specifications and Dimensions; TA50 RT Operating Dimensions and Limits; TA50 RT Operational Design Specifications

Model TA50RT
Rev. 1 04/99
SPECIFICATIONS
1
1 - 1
1.1 DESIGN SPECIFICATION
1.1.1 CLOSED DIMENSIONS AND WEIGHTS
Length ...................................................................................................................................5.65 m
Width .....................................................................................................................................2.20 m
Height .....................................................................................................................................2.26 m
Unladen Weight .....................................................................................................................7100 kg
1.1.2 OPERATING DIMENSIONS
Maximum Cage Floor Height .................................................................................................14.80 m
Maximum Working Height .....................................................................................................16.80 m
Maximum Working Outreach .....................................................................................................9.1 m
Standard Platform Dimensions ...................................................................................1.50 m x 0.60 m
Outside Turning Radius ............................................................................................................5.50 m
Gradability .........................................................................................................................50% (45°)
Maximum Speed, Booms Stowed ................................................................................5 km/hr (3mph)
Maximum Speed, Booms Elevated .......................................................................0.75 km/hr (0.5mph)
Ground Clearance ....................................................................................................................0.28 m
Maximum Wheel Loading........................................................................................................2950 kg
1.1.3 DESIGN SPECIFICATION
Safe Working Load (2 persons) ...................................................... ..........................225 kg (500 lbs)
Maximum Horizontal Platform Pull .......................................................................................... 400 N
Maximum Wind Speed ..................................................................... 12.5 m/sec (28 mph - 45 km/hr)
Maximum Slope for Safe Operation .................................................................................................5°
Full Range Time Up Min........................................................................................................100 secs
Full Range Time Down ............................................................................................................70 secs
Swing Left/Right .....................................................................................................................85 secs
Maximum Noise Emmission.......................................................................................72 dB(A) @ 3m
Temperature Operating Range......................................................................................-5°C to +40°C
