Model TA50RT
Rev. 1 04/99
MAINTENANCE SCHEDULES
5
5 - 22
5.4.2. Slew Bearing/Gear Lubricants
5.4.2.1. Slew Bearing Lubrication
Terex Aerials recommends lubrication of the slew bearing with an EP2 grease.
The slewing rings are equipped with greasing holes tapped to the European standard and suitable for:
- Centralised greasing.
- Standard greasing; straight or angled spherical head grease nipples
(AFNOR norms NFR 165-21 - DIN 3410)
Lubrication Frequency - Slew Bearing
- Regular Operation ........................................... every 100 hours
- Intensive Operation ........................................ every 50 hours
Note:- The slewing ring should be rotated through 360
o
after the lubrication operation and the lubricants
should then be topped up.
