Tesmec PT2450 - Hydraulic System Area

HYDRAULICPULLER‐TENSIONERPT2450
Tab
l
e:M
I
‐PT245
0
‐05
0
‐0
0
‐I
T
 Data:0
6
.08.2018
A
utor:
A
M Page:
7
di11
Table 5 – Hydraulic System Area
1. Hydraulic engine – Negative brake –
Main circuit gearbox;
2. Hydraulic oil filter;
3. Hydraulic oil load cap;
4. Hydraulic oil level;
5. Hydraulic oil drain faucet.
1
2
3
4
5
