HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 12 of 89
4. TRANSPORT AND POSITIONING INSTRUCTIONS
4.1 MACHINE LIFTING
For the machine lifting use only devices as overhead travelling cranes or lift trucks, with a capacity equal
to the mass to be lifted.
The instruments used for the machine lifting (ropes, cables, hooks, etc.) have to be exactly dimensioned
as compared to the mass to be lifted and have to be connected to the proper elements foreseen on the
machine.
For lifting of individual units refer to the corresponding table.
During machine lifting operations, the presence of persons on board the machine is strictly forbidden.
The total no dry mass relative to the lifting points and at the center of gravity is shown in the figure below:
8350 kg
PERSONAL PROTECTION
During lifting operations, it is necessary for the operator to use
all the safety equipment and personal protection equipment
required.
Safety shoes
Protective helmet
Hearing protection
Gloves
