Tesmec PT2450 - Control Panel; Radio Control

HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 17 of 89
5.4 CONTROL PANEL and RADIO CONTROL
The machine is equipped with a control panel on the electric box and a radio remote control to handle the
stringing operation.
The location and meaning of the elements placed on the control panel are described in the enclosed table
Control Panel
Printer Connection
Radio control
receiving
Diesel engine
switch on
Emergency Stop
USB Connection
Switch on key
GPS control
receiving
ELECTRIC
BOX
