Tesmec PT2450 - Safety Conditions and Risk Management; 7. Safety Conditions

HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 78 of 89
• Machine in “PULLER” configuration:
With the joystick of the MASTER machine it is possible to set the recovery speed on all machines, while
via the joystick of the SLAVE machines, it’s possible to make a small adjustment on the recovery speed of
the single circuit, depending on the value set on the master.
In this way, the operator can manually adjust the height of the wire or wire according to the line and the
various stretching operations that are being carried out.
Set pull force on
SLAVE machine
± XX KN
on MASTER
MACHINE
Set pull force in
all machine
XX KN
Set speed value on
the SLAVE machine
± XX Km/h
on MASTER
MACHINE
Set speed value in
all machine
XX Km/h
