Tesmec PT2450 - Pull Recording Menu; “Printer Setting” Button

HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 34 of 89
5.5.2.1 Pull Recording Menu
Between the menù “Pull recording menù” it’s possible to :
• Betwwen the “REC” button of the relative circuite, it’s possible record the key parameters of the
machine during the stringing operations. It’s possible to print the record simultanelly during the
stringing opearation or in a second time with the external printer;
• The “ACK” button allow to see the recording data;
• Save the recording in PDF format;
• Setting the parameter between the menù “Printer setting”;
“Printer setting” button:
Pressing the "Printer Setting" button you can set the parameters that will be displayed in the recordings
during the stringing operations:
Viewing Record
selected
Registered file
upwards scroll
Registered file
downwards scroll
Printer
S
ettings
Registration
START
and printing
Sub-menu EXIT
Exit to Main
menu
Data Reset
Increment and
decrement the
selected parameter
Pull recorder
parameters
setting
