HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 56 of 89
f. Through the dedicated button, select the operating mode in which you want to use the machine (PULLER
or TENSIONER).
This button displays the appropriate scale on the virtual dynamometer, depending
on the chosen configuration.
Refer to the symbolist specified in chapter 5.5.1.
g. Only for the first circuit, if necessary set the gear lever on the machine gear box, depending on whether
you want to work with the normal scaling dynamometer (0 a 50 KN) or if you want to use a FINE scaling (0
to 17 KN).
ATTENTION: Never change the position of the shift lever without first discharging
the line pull, in order to avoid the loss of the rope / conductor.
h. Choose machine usage configuration: Fully independent circuits, electronically connected circuits or
coupled circuits. (see chapter 5.5.2.3).
i. Check the machine parameters through the main work screen (see Working Menu par.5.5.2)
ATTENTION: During the sequence of cold start leave turn the vacuum machine
for about 10 minutes.
ATTENTION: In case of cold starts, after having pre-heated the hydraulic oil as
described above, the start of stringing operations for limiting at least the first 15
minutes the maximum performance of work (not exceed 30% of the maximum
speed of recovery).
