7 First steps
19
7.6 Connect probes
Flue gas probes
Instrument is switched on.
Insert the connector plug into the flue
gas socket and lock it in place by
turning it slightly clockwise (bayonet
lock).
There must be no more than one extension line (0554 1201) between
measuring instrument and flue gas probe.
Temperature adapter
Instrument is switched on.
Insert the connector plug of the
probe into the probe socket.
System recognizes the probe (info is displayed).
The parameter which is measured with an external probe is identified
on the display by "ext.".
