9 Performing the measurement
75
Reading is displayed.
Stabilization time is finished.
End stabilization time early: tap .
Measuring time starts.
The readings are automatically saved and displayed after the
measurement has been completed.
The measuring value result can be assessed.
Conclude measurement: tap Next.
If applicable, repeat measurement: tap .
9.5.17 4 Pa measurement
The 4 Pa measurement is only available with instruments that have the
dilution option available.
Call up function: | 4 Pa measurement
Set parameters or enter values.
All values that can be modified have a dotted underlining.
Connect adapter 0554 1203, hose connection kit and capillary hoses
0554 1215 as shown in the illustration.
Hose test is started.
Measurement starts.
Readings and measuring time are displayed.
