Assembly
15
Water drain
The water is conveyed through the measuring chamber via an open
funnel and the drain hose installed on the same and into the duct.
Remove the supplied funnel and accommodate it underneath, in
the recess of the housing designated for that purpose.
Connect the funnel of the Testomat
®
EVO TH CAL with a drain
hose (internal diameter 12 mm/14 mm)
Lay this hose free of back pressure and without the siphon effect
to the drain
Connect mains and devices
Risk of injury from assembly when voltage present!
Unless you disconnect the power supply before commencing assem-
bly, you risk injury, destruction of the product or damage to system
components.
Disconnect all power to the relevant system component before
assembling the Testomat
®
EVO TH CAL device.
When connecting, use only verified cables with sufficient line
cross-section.
Disconnecting device for the power supply
The unit has no power switch!
Fit the Testomat
®
EVO TH CAL with a switch as a disconnecting
device for the power supply. Use an appliance switch or a circuit
breaker that meets the requirements of IEC 608947-1 and IEC
60947-3.
The switch must be within easy reach of the user of the Testomat
®
EVO TH CAL and clearly marked as a disconnecting device for the
Testomat
®
EVO TH CAL.
For disconnection, you can also provide a three-pin plug near the
device, which is clearly marked as a disconnecting device for the
Testomat
®
EVO TH CAL.
Danger of damage due to electromagnetic fields!
If you assemble the Testomat
®
EVO TH CAL device or connecting
cables parallel to mains cables or in the vicinity of strong electro-
magnetic fields, the device may be damaged or the measurement
disrupted.
Keep the connecting cables as short as possible
Lay the connecting cables and mains cables separately.
Connect the device with the protective conductor (at 230/100-240
VAC).
Keep interference voltages away from the Testomat
®
EVO TH CAL
device – e.g. by using a mains filter.
