Testomat EVO TH CAL - During Assembly; During Operation

Important safety information
8
During assembly
 Always disconnect the relevant system component from the power
source before assembling the device or connecting it to the power
supply or disconnecting it from the same. Prevent any inadvertent
reactivation of the device.
 Only connect the device to the mains voltage as specified on the
type plate.
 Observe the technical data and the environmental parameters.
 The connections for mains voltage and relay outputs must be laid
separately from each other, to guarantee corresponding insulation
between the cables. Accordingly, do not operate the device if the
partition walls or terminal area covers are not present.
Avoiding interference voltages
The Testomat
®
EVO TH CAL device requires stable and uninterrupt-
ed supply voltage. Where applicable, use a mains filter to shield the
Testomat
®
EVO TH CAL device from interference voltages, which
may be generated for example within the network by magnetic valves
or large-scale engines. Never lay the connecting cables in parallel to
mains cables.
Handling may cause damage or destruction of electrical compo-
nents!
If you need to open the upper door, you should take the necessary
safety measures to avoid electrostatic discharge onto the compo-
nents (ESD safety).
Make sure you are earthed before opening the casing.
During operation
 The device has no power switch.
Use an external power switch to turn the unit on and off. The
switch must be installed next to the device and must be marked as
power switch for the device - for example with a label.
 Ensure that the maximum electrical load capacity of the switching
outputs is not exceeded, particularly for inductive loads. The power
supply for the user inclusive device is secured with a 4A fuse,
which means the total of all loads must not reach 4A.
 In the event of any malfunctions, immediately switch off the Tes-
tomat
®
EVO TH CAL device and inform the service personnel.
Never attemt to repair the Testomat
®
EVO TH CAL device your-
self. Doing do will invalidate the guarantee. Repairs must be per-
formed by authorized service personnel only.
WARNING
!
NOTE
ATTENTION
!
