Error messages/troubleshooting
64
LED1
LED2
LED3
LED4
LED5
Error number/text
in alarm log on SD
card
Solution, troubleshooting measures
☼
○
○
○
○
500 CTRL-FRAM
IC2
1. Defective component. Repair/exchange
required.
☼
501 MB-IC12
See 1.
☼
☼
○
○
○
502 HMI-IC1
See 1.
○
○
☼
○
○
503 HMI-IC2
2. Loose cable between motherboard and
display?
If not: Defective, repair required.
☼
☼
○
○
504 HMI-IC5
See 2.
○
☼
☼
○
○
505 MB-IC2
See 1.
☼
☼
☼
○
○
506 MB-IC5
See 1.
○
○
○
☼
507 MB-IC3
See 1.
☼
○
○
☼
508 MB-IC4
See 1.
○
☼
○
☼
509 MB-IC6
See 1.
☼
☼
○
☼
510 Font file
3. Character set or menu language could
not be read.
Internal SD card inserted and locked?
If yes, perform firmware update again. If the
error persists, a repair is required.
○
○
☼
☼
511 Font info
See 3.
☼
○
☼
☼
512 Font char
See 3.
○
☼
☼
☼
513 Language file
See 3.
☼
☼
☼
☼
☼
514 Language
header
See 3.
☼
515 Language info
See 3.
☼
☼
516 Menu entry not
found
See 3.
☼
☼
517 Language mag-
ic
See 3.
☼
☼
☼
518 Fifo overflow
Software error. Firmware update required.
☼
☼
519 DAC Calibration
invalid
Calibration of the DAC of the 20mA current
loop is invalid. Device must be recalibrated
in the factory.
☼
☼
☼
520 Wrong firmware
Wrong firmware for this device, install correct
firmware
☼ : Rapidly flashing LED (around 10 Hz). LED1 is below or next to
the plug connector to the motherboard.
