Error messages/troubleshooting
66
LED1
LED2
LED3
LED4
LED5
Error number/text
in update.txt
On SD card
Solution, troubleshooting measures
☼
○
○
○
○
900 No SD-Card in-
serted
Insert SD card, restart firmware update
○
☼
○
○
○
901 SD-Card write
protect
Confirm write-protect tab on the side of
the card, restart firmware update
☼
○
○
902 SD-Card init. failed
Re-insert SD card, restart firmware up-
date.
In the event of multiple failures, a defect
is present and repair is required.
○
○
☼
○
903 SD-Card unfor-
matted
Format SD card, restart firmware update
☼
☼
☼
☼
☼
904 SD-Card read
error
Inserted SD card defective. Initially re-
place card.
If the defect persists, even after the re-
placement: Repair
☼
☼
☼
☼
905 PCB SD read error
Internal micro SD card defective: Repair
☼
☼
☼
☼
906 PCB SD write
error
Internal micro SD card defective: Repair
☼
○
☼
☼
☼
907 PCB SD init failed
Internal micro SD card defective: Repair
☼
☼
○
☼
☼
908 FRAM read error
Read error in internal I²C FRAM: Repair
☼
☼
☼
☼
909 FRAM write error
Write error in internal I²C FRAM: Repair
☼
☼
☼
910 Flash control busy
Initialization error STM32 Flash: Repair
○
○☼
☼
☼
911 Flash program
error
Programming error STM32 Flash: Repair
☼
☼
☼
912 Flash write protect
Write protection STM32 Flash: Repair
☼
☼
☼
913 Flash timeout
Timeout STM32 Flash: Repair
☼
☼
914 UPD file invalid
Invalid update file. Re-download
☼
☼
915 UPD sec invalid
type
Section in update file defective: Re-
download
☼ : Rapidly flashing LED (around 10 Hz). LED1 is below or next to
the plug connector to the motherboard.
