Table 3-15. TI 60-Pin Connector (J33) Pin-Out
Pin No. Signal Pin No. Signal
1 VCC3V3_R 31 MIPI_TRC_DAT06
2 MIPI_TMS_R 32 NC
3 JTAG_MIPI_TCK 33 MIPI_TRC_DAT07
4 MIPI_TDO_R 34 NC
5 MIPI_TDI_R 35 MIPI_TRC_DAT08
6 MIPI_EMU_RSTn 36 NC
7 MIPI_RTCK 37 MIPI_TRC_DAT09
8 MIPI_TRST#_R 38 JTAG_MIPI_EMU0
9 NC 39 MIPI_TRC_DAT10
10 NC 40 JTAG_MIPI_EMU1
11 NC 41 MIPI_TRC_DAT11
12 VCC_3V3_MIPI 42 NC
13 MIPI_TRC_CLK 43 MIPI_TRC_DAT12
14 NC 44 NC
15 DGND 45 MIPI_TRC_DAT13
16 DGND 46 NC
17 MIPI_TRC_CTL 47 MIPI_TRC_DAT14
18 MIPI_TRC_DAT19 48 NC
19 MIPI_TRC_DAT00 49 MIPI_TRC_DAT15
20 MIPI_TRC_DAT20 50 NC
21 MIPI_TRC_DAT01 51 MIPI_TRC_DAT16
22 MIPI_TRC_DAT21 52 NC
23 MIPI_TRC_DAT02 53 MIPI_TRC_DAT17
24 MIPI_TRC_DAT22 54 NC
25 MIPI_TRC_DAT03 55 MIPI_TRC_DAT18
26 MIPI_TRC_DAT23 56 NC
27 MIPI_TRC_DAT04 57 DGND
28 NC 58 SEL_XDS100_INV
29 MIPI_TRC_DAT05 59 NC
30 NC 60 NC
System Description www.ti.com
24 AM64x/AM243x GP EVM User's Guide SPRUIX0C – FEBRUARY 2021 – REVISED JUNE 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

Texas Instruments AM64 Series Specifications

General

Core Count	Up to 4x Cortex-A53, Up to 2x Cortex-R5F, 1x Cortex-M4F
Package Type	FCBGA
Operating Temperature	-40°C to 105°C (Industrial)
Architecture	Arm Cortex-A53, Arm Cortex-R5F, Arm Cortex-M4F
Memory Support	DDR4, DDR3L
I/O Interfaces	USB, PCIe, CAN, UART, SPI, I2C, McASP
Series	AM64
Category	Processor
Security Features	Secure Boot, Cryptographic Acceleration
Ethernet	Gigabit Ethernet with TSN support
Industrial Protocols	EtherCAT, PROFINET
Peripherals	ADC, Timers, PWM, Watchdog
