3.4.10 Display Interface
The display device used on the EVM is an OSD9616P0992-10 from OSD Displays. This is a passive matrix
PMOLED display with monochrome (light blue) backlight. The display has a pixel array of 96X16 and a panel
size of 29.10 X 9.20 X 1.30 (mm) and an active area of 21.1 X 3.5 (mm). The display is connected to the 14-Pin
FPC connector on the EVM having part number 10051922-1410ELF from Amphenol ICC and the pin details are
mentioned in Table 3-21.
Table 3-21. Display Connector (J36) Pin-Out
Pin No. Signal
1 C2P
2 C2N
3 C1P
4 C1N
5 VDDB
6 NC
7 VSS
8 VDD
9 RES#
10 SCL
11 SDA
12 IREF
13 VCOMH
14 VCC
