Table 3-24. Selection of PRG0 Signals on Application Connector (continued)
Connector
Pin SoC Ball Net Name Pin Multiplexed Signal Functions
C5 R6 PRG0_PRU0GPO13 PRG0_PRU0_GPI13,
PRG0_RGMII1_TD2 ,PRG0_PWM0_B0, SPI3_D0,
GPIO1_13, GPMC0_A15
C6 R3 PRG0_PRU0GPO5 PRG0_PRU0_GPI5, PRG0_PWM3_B2, GPIO1_5,
UART3_RTSn
C7 - DGND -
C8 T4 PRG0_PRU1GPO3 PRG0_PRU1_GPI3, PRG0_RGMII2_RD3, GPIO1_23,
EQEP1_A, GPMC0_A18, UART6_CTSn
C9 V4 PRG0_PRU0GPO14 PRG0_PRU0_GPI14,
PRG0_RGMII1_TD3,PRG0_PWM0_A1, SPI3_D1,
GPIO1_14, GPMC0_A3
C10 - DGND -
C11 U5 PRG0_PRU1GPO15 PRG0_PRU1_GPI15, PRG0_RGMII2_TX_CTL,
PRG0_PWM1_B1, GPIO1_35 , GPMC0_A10,
PRG0_ECAP0_IN_APWM_OUT
C12 V12 PRG1_PRU1GPO19 PRG1_PRU1_GPI19,
PRG1_IEP1_EDC_SYNC_OUT0,
PRG1_PWM1_TZ_OUT, RGMII1_RD3,
RMII1_CRS_DV, SPI3_CS2, GPIO0_84,
UART5_RTSn, PRG1_ECAP0_IN_APWM_OUT
C13 - DGND -
C14 T18 GPMC0_AD2 FSI_RX2_D1 , UART2_RTSn, EHRPWM_TZn_IN0,
TRC_DATA0, GPIO0_17, PRG0_PWM2_TZ_IN,
BOOTMODE02
C15 U19 GPMC0_AD5 FSI_RX3_D1, UART3_RTSn, EHRPWM1_A,
TRC_DATA3, GPIO0_83, PRG0_PWM2_A1,
BOOTMODE05
C16 - DGND -
C17 - DGND -
C18 - DGND -
C19 - DGND -
C20 - DGND -
C21 W21 GPMC0_AD12 FSI_RX1_D0, UART6_CTSn, EQEP1_B,
TRC_DATA10, GPIO0_27, EHRPWM7_B,
BOOTMODE12
C22 - HSE_GPIO0_32 -
C23 - HSE_GPIO0_34 -
C24 - HSE_GPIO0_37 -
C25 - DGND -
C26 - HSE_GPIO0_39 -
C27 R2 HSE_PRG0_PRU1_GPO19 PRG0_PRU1_GPI19,
PRG0_IEP1_EDC_SYNC_OUT0,
PRG0_PWM1_TZ_OUT, MDIO0_MDC,
RMII1_CRS_DV, EHRPWM7_B, GPIO1_39,
PRG0_ECAP0_IN_APWM_OUT
C28 V5 HSE_PRG0_PRU1_GPO17 PRG0_PRU1_GPI17,
PRG0_IEP1_EDC_SYNC_OUT1 , PRG0_PWM1_B2,
RGMII1_RD3, RMII1_TXD1,
GPIO1_37, PRG0_ECAP0_SYNC_OUT,
PRG0_ECAP0_SYNC_IN
C29 D17 HSE_MCAN1_RX/I2C3_SDA ECAP2_IN_APWM_OUT, OBSCLK0, TIMER_IO5,
UART5_TXD, EHRPWM_SOCB, GPIO1_63,
EQEP2_B, UART0_DSRn
C30 - DGND -
E1 A18 SOC_I2C0_SCL UART6_CTS, GPIO1_64
