Capture Units
reserved
Capture FIFO Status Register
Capture FIFO Status Register
(EVA)
(EVA)
CAPFIFOA @ 0x007422
CAPFIFOA @ 0x007422
(lab file:
(lab file:
Ev
Ev
.c)
.c)
13-12 9-811-10
CAP3FIFO CAP2FIFO CAP1FIFO
FIFOx Status:
00 = empty
01 = one entry
10 = two entries
11 = three entries attempted,
1st entry lost
CAPxFIFO bits are
automatically adjusted on a
capture or FIFO read
15-14
reserved
7-0
C28x - Event Manager 7 - 31
