General-Purpose Digital I/O

C28x GPIO Data Registers

(lab file:

Gpio

.c)

Address

Name

0x0070E0

GPADAT

GPIO A Data Register

0x0070E1

GPASET

GPIO A Set Register

0x0070E2

GPACLEAR

GPIO A Clear Register

0x0070E3

GPATOGGLE

GPIO A Toggle Register

0x0070E4

GPBDAT

GPIO B Data Register

0x0070E5

GPBSET

GPIO B Set Register

0x0070E6

GPBCLEAR

GPIO B Clear Register

0x0070E7

GPBTOGGLE

GPIO B Toggle Register

0x0070EC

GPDDAT

GPIO D Data Register

0x0070ED

GPDSET

GPIO D Set Register

0x0070EE

GPDCLEAR

GPIO D Clear Register

0x0070EF

GPDTOGGLE

GPIO D Toggle Register

0x0070F0

GPEDAT

GPIO E Data Register

0x0070F1

GPESET

GPIO E Set Register

0x0070F2

GPECLEAR

GPIO E Clear Register

0x0070F3

GPETOGGLE

GPIO E Toggle Register

0x0070F4

GPFDAT

GPIO F Data Register

0x0070F5

GPFSET

GPIO F Set Register

0x0070F6

GPFCLEAR

GPIO F Clear Register

0x0070F7

GPFTOGGLE

GPIO F Toggle Register

0x0070F8

GPGDAT

GPIO G Data Register

0x0070F9

GPGSET

GPIO G Set Register

0x0070FA

GPGCLEAR

GPIO G Clear Register

0x0070FB

GPGTOGGLE

GPIO G Toggle Register

C28x - System Initialization 5 - 13
