Texas Instruments MSPM0G3507 User Manual

Table 6-3. Signal Descriptions (continued)
FUNCTION
SIGNAL
NAME
PIN NO.
(1)
PIN TYPE
(2)
DESCRIPTION
64 PM
48 PT,
RGZ
32
RHB
28
DGS28
GPIO
PA0 33 1 1 4 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA1 34 2 2 5 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA2 42 8 6 9 I/O General-purpose digital I/O
PA3 43 9 7 10 I/O General-purpose digital I/O
PA4 44 10 8 11 I/O General-purpose digital I/O
PA5 45 11 9 12 I/O General-purpose digital I/O
PA6 46 12 10 13 I/O General-purpose digital I/O
PA7 49 13 11 – I/O General-purpose digital I/O
PA8 54 16 12 – I/O General-purpose digital I/O
PA9 55 17 13 14 I/O General-purpose digital I/O
PA10 56 18 14 15 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA11 57 19 15 16 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA12 5 27 16 – I/O General-purpose digital I/O
PA13 6 28 17 – I/O General-purpose digital I/O
PA14 7 29 18 17 I/O General-purpose digital I/O
PA15 8 30 19 18 I/O General-purpose digital I/O
PA16 9 31 20 19 I/O General-purpose digital I/O
PA17 10 32 21 20 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA18 11 33 22 21 I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA19 12 34 23 22 I/O General-purpose digital I/O
PA20 13 35 24 23 I/O General-purpose digital I/O
PA21 17 39 25 24 I/O General-purpose digital I/O
PA22 18 40 26 25 I/O General-purpose digital I/O
PA23 24 43 27 26 I/O General-purpose digital I/O
PA24 25 44 28 27 I/O General-purpose digital I/O
PA25 26 45 29 28 I/O General-purpose digital I/O
PA26 30 46 30 1 I/O General-purpose digital I/O
PA27 31 47 31 2 I/O General-purpose digital I/O
PA28 35 3 – – I/O
General-purpose digital I/O with wake up from
SHUTDOWN
PA29 36 – – – I/O General-purpose digital I/O
PA30 37 – – – I/O General-purpose digital I/O
PA31 39 5 – – I/O
General-purpose digital I/O with wake up from
SHUTDOWN
