Texas Instruments RM46L852 User Manual

PRODUCTPREVIEW
RM46L852
www.ti.com SPNS185 –SEPTEMBER 2012
Table 2-1. PGE Multi-Buffered Analog-to-Digital Converters (MibADC1, MibADC2) (continued)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
AD1IN[08] / AD2IN[08] 83 Input - - ADC1/ADC2 shared
analog inputs
AD1IN[09] / AD2IN[09] 70
AD1IN[10] / AD2IN[10] 72
AD1IN[11] / AD2IN[11] 75
AD1IN[12] / AD2IN[12] 77
AD1IN[13] / AD2IN[13] 79
AD1IN[14] / AD2IN[14] 82
AD1IN[15] / AD2IN[15] 85
AD1IN[16] / AD2IN[0] 58
AD1IN[17] / AD2IN[01] 59
AD1IN[18] / AD2IN[02] 62
AD1IN[19] / AD2IN[03] 63
AD1IN[20] / AD2IN[04] 64
AD1IN[21] / AD2IN[05] 65
AD1IN[22] / AD2IN[06] 81
AD1IN[23] / AD2IN[07] 84
MIBSPI3SOMI/AWM1_EXT_ENA/ECAP2 51 Output Pull Up - AWM1 external analog
mux enable
MIBSPI3SIMO/AWM1_EXT_SEL[0]/ECAP3 52 Output Pull Up - AWM1 external analog
mux select line0
MIBSPI3CLK/AWM1_EXT_SEL[1]/EQEP1A 53 Output Pull Up - AWM1 external analog
mux select line0
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 11
Submit Documentation Feedback
