RM46L852
SPNS185 –SEPTEMBER 2012 www.ti.com
2.3.1.2 Enhanced High-End Timer Modules (N2HET)
Table 2-2. PGE Enhanced High-End Timer Modules (N2HET)
Terminal Signal Default Pull Pull Type Description
Type State
Signal Name 144
PGE
N2HET1[0]/SPI4CLK/EPWM2B 25 I/O Pull Down Programmable,
N2HET1 time input
20uA
N2HET1[01]/SPI4NENA/USB2.TXEN/ 23
capture or output
USB_FUNC.PUENO/N2HET2[8]/EQEP2A
compare, or GIO.
N2HET1[02]/SPI4SIMO/EPWM3A 30
Each terminal has a
suppression filter that
N2HET1[03]/SPI4NCS[0]/USB2.SPEED/ 24
ignores input pulses
USB_FUNC.PUENON/N2HET2[10]/EQEP2B
smaller than a
N2HET1[04]/EPWM4B 36
programmable duration.
N2HET1[05]/SPI4SOMI/N2HET2[12]/EPWM3B 31
N2HET1[06]/SCIRX/EPWM5A 38
N2HET1[07]/USB2.PortPower/USB_FUNC.GZO/ 33
N2HET2[14]/EPWM7B
N2HET1[08]/MIBSPI1SIMO[1]/ 106
USB1.OverCurrent
N2HET1[09]/N2HET2[16]/USB2.SUSPEND/ 35
USB_FUNC.SUSPENDO/EPWM7A
N2HET1[10]/MII_TX_CLK/USB1.TXEN 118
/MII_TX_AVCLK4/nTZ3
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/ 6
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO
N2HET1[12]/MII_CRS/RMII_CRS_DV 124
N2HET1[13]/SCITX/EPWM5B 39
N2HET1[14]/USB1.TXSE0 125
N2HET1[15]/MIBSPI1NCS[4]/ECAP1 41
N2HET1[16]/EPWM1SYNCI/EPWM1SYNCO 139
MIBSPI1NCS[1]/N2HET1[17]/MII_COL/ 130 Pull Up
USB1.SUSPEND/EQEP1S
N2HET1[18]/EPWM6A 140 Pull Down
MIBSPI1NCS[2]/N2HET1[19]/MDIO 40 Pull Up
N2HET1[20]/EPWM6B 141 Pull Down
N2HET1[22]/USB2.TXSE0/USB_FUNC.SE0O 15
MIBSPI1NENA/N2HET1[23]/MII_RXD[2]/ 96 Pull Up
USB1.VP/ECAP4
N2HET1[24]/MIBSPI1NCS[5]/MII_RXD[0]/RMII_RXD[0] 91 Pull Down
MIBSPI3NCS[1]/N2HET1[25]/MDCLK 37 Pull Up
N2HET1[26]/MII_RXD[1]/RMII_RXD[1] 92 Pull Down
MIBSPI3NCS[2]/I2C_SDA/N2HET1[27] 4 Pull Up
N2HET1[28]/MII_RXCLK/RMII_REFCLK/MII_RX_AVCLK4 107 Pull Down
MIBSPI3NCS[3]/I2C_SCL/N2HET1[29]/nTZ1 3 Pull Up
N2HET1[30]/MII_RX_DV/USB1.SPEED/EQEP2S 127 Pull Down
MIBSPI3NENA/MIBSPI3NCS[5]/N2HET1[31] 54 Pull Up
GIOA[5]/EXTCLKIN/EPWM1A/N2HET1_PIN_nDIS 14 Pull Down
